Products Details
| Type | Broaching, Drilling, Etching / Chemical Machining, Laser Machining, Milling, Other Machining Services |
| Material Capabilities | Brass, Aluminum, Copper, Stainless Steel, Steel Alloys |
| CNC Machining or Not | CNC Machining |
| Micro Machining or Not | Not Micro Machining |
| Material Purity | High-purity copper ≥99.9%, optional copper alloys (Cu-Ni, Cu-Sn) |
| CNC Machining Tolerance | ±0.005mm precision, multi - axis milling for complex channel designs |
| Surface Finish Options | Polishing, nickel plating, anodizing; Ra 0.8-1.6μm for heat transfer |
| Thermal Conductivity | ≥401W/(m K) , optimized by internal micro-channel structures |
| Application Compatibility | High-end GPU, server CPU, 5G base stations, industrial power module |
| Customization Flexibility | CAD - driven design, micro - channels/grooves added via precision CNC |
| Pressure Resistance | Withstand up to 10 bar, suitable for liquid - cooled cooling systems |
| Thickness Customization | 1mm - 20mm thickness range, ultra - thin (≥1mm) for compact devices |
| Certification Compliance | ISO-9001,ISO-14001,ISO-45001, ISO-IATF 16949 |
| Lead Time for Samples | Sample: 5 - 7 days; Mass order: 2 - 3 weeks, rush service available |
| Selling Units | Single item |
| Package size per batch | 8X7X3 cm |
| Gross weight per batch | 0.800 kg |
+
FAQ
1. What is a VC Heat Spreader?
A VC Heat Spreader is a device that enhances heat dissipation in electronic components using vapor chamber technology.
2. Why use copper in heat spreaders?
Copper is used in heat spreaders for its excellent thermal conductivity, improving heat dissipation efficiency.
3. How does a heat spreader improve device lifespan?
By reducing overheating, a heat spreader extends the lifespan of electronic components.
4. Can the heat spreader be customized?
Yes, our heat spreaders can be customized to fit different device sizes and requirements.
5. What applications benefit from a copper heat spreader?
High-performance computing and electronics applications benefit from copper heat spreaders due to improved thermal management.
6. Is the heat spreader easy to integrate?
Yes, the lightweight design ensures easy integration into existing systems.
7. Does the heat spreader offer uniform heat distribution?
The heat spreader provides uniform heat distribution across its surface area.
8. Is the manufacturing process environmentally sustainable?
Yes, our manufacturing process for heat spreaders is environmentally sustainable.
